RK3588 Core Board
High-Performance AI Computing Power
- 8nm Process, 8-Core 64-Bit Processor, NEON Coprocessor
- Gigabit High-Speed Ethernet Port
- 8K@30Hz or 4K@120Hz Video Codec Capability
- Industrial Grade Support -40℃~85℃
- 4-in-3-out HDMI Interface Supports Up to 8K@60Hz Input
- Interface Support:
2x HDMI-TX 2.1, Up to 8K@60Hz
1x HDMI-RX 2.0, Up to 4K@60Hz
1x MIPI DSI TX 4 Lane / 1x DP-TX Up to 7680x4320@30Hz
1x BT.1120 Up to 1920x1080@60Hz
- Integrated ARM Mali-G610 Built-in 3D GPU Compatible with OpenGLES1.1/2.0/3.2, OpenCL 2.2, Vulkan 1.2
- INT4/INT8/INT16/FP16 Mixed Operations, 6 TOPS Computing Power
- Supports 2 USB3.0, 2 USB2.0
- Supports 6 MIPI Cameras
- Decoding Supports MPEG-1, MPEG-2, MPEG-4, H.263, H.264, H.265, VC-1, VP9, VP8, MVC, AV1 etc., Up to 8K@30Hz
- Encoding Supports H.264, H.265, Up to 8K@30Hz
|
