EN_HHN10 HDMI Encoder, Support Stream Pulling & Receiving Push Stream, Multi-Protocol Conversion, Ideal for Live Streaming, IPTV Broadcast, Security Monitoring, Video Conference & Remote Teaching

EN_HHN10 HDMI Encoder, Support Stream Pulling & Receiving Push Stream, Multi-Protocol Conversion, Ideal for Live Streaming, IPTV Broadcast, Security Monitoring, Video Conference & Remote Teaching

$165.00
$210.00 $165.00
Sale Sold out

The EN_HHN10 HDMI Video Encoder is a professional streaming transmission device designed for stable HD video encoding. It integrates comprehensive streaming functions including stream pulling, external push stream receiving and cross-protocol conversion. Supporting flexible signal format transformation, it ensures low-latency and high-quality video transmission. This encoder is widely applicable for live broadcast, IPTV system, security surveillance, business video conferencing, media distribution and remote video transmission scenarios with stable operation and strong compatibility.

Adopts EN_HHN10 professional HDMI encoding core, realizes stable high-definition video signal compression and transmission.
Supports both stream pulling and incoming push stream receiving for two-way flexible streaming management.
Built-in multi-protocol conversion function, achieves seamless conversion between mainstream streaming protocols.
Features low latency, high compatibility and stable output, suitable for long-time continuous working.
Ideal for live streaming, IPTV broadcasting, security monitoring, video conferencing and multimedia media transmission.

Technical Specifications
Input Interface: 1×HDMI
Input Resolution: Max. 1080P@60fps
Encoded Output Resolution: Max. 1080P@60fps
Network Input: Not supported
Local Loop Output: 1×HDMI
Loop-out Resolution: Same as input resolution
I-frame Output: Not supported
Streaming Protocols: RTMP, RTSP, FLV, HLS, SRT, TS, RTC, H5, UDP Multicast
Vertical Screen Output: Supported via network output
Network Streaming Streams: Main stream, Sub stream
Audio Input: 1×HDMI, 1×3.5mm Analog
Audio Output: 1×3.5mm Analog, Network Audio
Video Encoding Format: H.264, H.265
Encoding Profile: H.264 Baseline / Main / High; H.265 Main
Bitrate Control Mode: CBR, VBR, Strong CBR
Video Bitrate: 2 ~ 61440 kbps
Video Frame Rate: 5 ~ 30 fps
Keyframe Interval: 1 ~ 30
Intelligent Encoding: Not supported
Image Rotation: 90°, 180°, 270°
Image Flip Mode: Off, Mirror, Flip, Mirror & Flip
Image Cropping & Zoom: Adjustable left offset, top offset, height, width
OSD Functions: Text overlay, Image overlay, Time stamp overlay
Audio Encoding: AAC, G711A, G711U
Audio Source: 3.5mm analog audio, HDMI embedded audio
Audio Sampling Rate: 44.1kHz, 48kHz

Product description：

HDMI Encoder *1

Power Adapter*1

User Manual*1


View full details
